The use of computer vision will help augmented reality (AR) devices to build a more accurate augmented environment by helping it to determine where to place virtual images in accordance with real space.

AR devices use GPS and compass to figure out where a person is standing and what directions he or she is facing to display images against the real-world background. But if a person is moving around a bustling city or a congested area, then GPS tracking may not be accurate. As a result of such inaccuracy, AR devices might sometimes place virtual images at incorrect places and build inaccurate AR environments. Computer vision can help AR devices to address location challenges and build a more detailed and precise augmented environment.

Computer vision is a field of study that helps computers to understand images and videos. Computers are able to imitate the functioning of the human visual system with the help of computer vision. The capabilities of computer vision to decipher images and videos have paved the way for its various applications like optical character recognition, machine inspection, 3D model building, and others. AR devices can use some of these applications for creating their artificial environments and seamlessly merge them with real environments. But, before finding out how computer vision for AR can help the latter to build accurate augmented environments, let’s understand some common methods that computer vision uses to decipher and sort the visible world.

1. Methods Used by Computer Vision to Understand the Visible World


Computer vision uses several methods that help it to decipher images and extract knowledge from them. Some of these methods are: Blob Detection

Blob detection methods aim to detect different regions in an image based on several properties like brightness or contrast in comparison to other surrounding regions. A blob in an image is defined as a region where some of the properties are constant or approximately constant. Thus using blob detection, computer vision can easily classify say, for example, a bush from its surroundings.


Scale-space is a theory built to handle an image structure at different scales. This theory breaks down an image to its most basic elements to better understand the properties of the image at multiple scales. Template Matching

Template matching is a method that can find small pieces of an image that matches a provided template or image. For instance, this method is used in facial recognition. Every face has its unique features, and a template matching method can match a real face with the face on an image stored in a database. Edge Detection

The edge detection method includes identification of key points in images where brightness sharply changes or ceases. These points are organized in a set of curved lines termed edges. It is a method to find discontinuities in an image. This method in computer vision is mostly used for feature detection or feature extraction.

2. Applications of Computer Vision in Augmented Reality

With the help of the above methods and several others, computer vision can help AR devices to not only build augmented environments but also provide information to users.

How Computer Vision Can Help in Building Augmented Reality Environments Convolutional Neural Networks

Any mapping technique that helps AR devices to determine a camera’s location in the real environment, along with a 3D model of virtual environments, needs different techniques like CNN to determine the location of different objects of the real world. When trained with several images of an object, CNN can accurately identify, localize, and classify that object in an image. These networks have many use cases for AR. For instance, they can be used for facial-detection and recognition. Once a face is detected, AR systems can gather information about that person from social media platforms and add his or her information to the AR environment. Updating a person’s information to the AR environment can help law enforcers. Law enforcers can use AR device to get previous criminal records of criminals in real-time. SLAM (Simultaneous Localization And Mapping)

SLAM is an important technology for AR that uses physical data to construct maps through feature points. Feature points are detected landmarks of an image that is fed into the SLAM system, which is detected with the help of computer vision. This technology allows AR devices to recognize 3D objects. SLAM has the ability to build 3D maps along with simultaneously tracking the position of AR devices, allowing them to build augmented environments in real-time. Since SLAM is capable of building maps, it has many use cases for AR technology. One such use case is in the field of advertising. For instance, a computer vision-enabled AR technology named Augmented Reality Digital Placement allows users’ to view web ads without the need for installing any separate application on their smartphones. With the help of this technology, companies can show rich media advertisements to web users for providing enhanced engagement. QR Codes Scanning

Computer vision has the ability to scan QR codes and collect information stored in it. And, AR can use the information gathered by CV by scanning QR codes to display that information to users. Customizable QR codes are placed on almost every physical product of a company to make it easier for businesses to recognize a product. QR codes are placed on almost every physical product of a company to make it easier for businesses to recognize a product. And hence, QR code applications can be used across all the industries. But, by using AR devices to show the product information can be useful for both customers and businesses. For instance, a company that makes packed food can enter the entire journey of the packed food like the ingredients, quality of ingredients, how the food was packed, and other information in a QR code and paste the code on the food packet. And then, consumers can use AR devices embedded with computer vision to scan the QR code and see the entire journey of the packet.

There are many ways where AR itself can transform warehouse management, but with the merge of AR and computer vision, warehouse management has become even simpler. For instance, manufacturers can scan the QR code of any packet and fetch details of how many exactly similar products are left in the inventory and manage it easily and efficiently. Also, they can allow customers to order the product with the help of QR code from an AR application.

Computer vision is not a new technology but rather an old one that has become affordable with continued research and innovation. Earlier, the data required to train computer vision was not easy to get, but now with technologies like IoT and big data, it has become easy to train computer vision programs. These technologies can constantly gather users’ data and analyze that data to extract knowledge from it. And hence, computer vision technology is now enabling a range of products that are more responsive and intelligent than before. The use of computer vision for AR devices is helping them to build a real looking augmented environment, which is helping them in mainstream adoption across all the industries.
